New Intercom Panel from Ufanet
Simple Installation.
Doesn’t require public IP.
Face recognition.
Copy-protected keys.
New Intercom Panel from Ufanet
Simple Installation.
Doesn’t require public IP.
Face recognition.
Copy-protected keys.
Key Features
Surface mounting in 30 minutes
A steel casing reduces the panel installation time by 8 times compared to flush mounting (according to the Ufanet service). The installation is universal and does not require special skills from engineers.
Copy-protected keys
The developed encryption system protects keys from copying. Uncopyable keys make it more difficult for unauthorized individuals to access the building, ensuring a higher level of security for residents.
Doesn’t require public IP
Thanks to the firmware 'Agent', the smart intercom automatically establishes a VPN tunnel with the servers required for operation.
Ultra-bright camera
The Secret Top camera with an ultra-bright matrix allows for capturing a color image even at night with minimal light.
Face recognition
A neural network accurately identifies residents and distinguishes a live person from a picture of a person.
Compatible with analog systems
Supports analog systems such as ELTIS, VIZIT, CYFRAL.
Payment control
Disconnection of the analog handset through the admin panel or API.
Administrator's control panel
For managing and configuring the intercom and mobile application.
Resident's mobile application
For audio and video calls, remote door opening, and much more.
Secret TOP is an IP panel that supports most popular intercom systems. The built-in reader operates at a frequency of 13.56 MHz (Mifare 1K standard), and the number of keys stored in the call block memory is unlimited. The Secret TOP call block is installed using the existing coordinate-matrix intercom system. Secret TOP can be installed in places where the intercom system incorporates gates or additional doors.
Panel specifications:
Intercom panel Secret TOP:
1. Supports connection to many popular intercom systems (Vizit, Eltis, CYFRAL)
2. Allows call redirection to the mobile phone application
3. Allows door opening through mobile phone application
4. Permits the door opening via face recognition
5. In case of loss of connection, continue to function as a regular intercom panel
6. Has the capability to use copy-protected RFID Mifare keys
7. Manages video surveillance of the surrounding area
Package contents:
1. Secret Top intercom (1 piece)
2. Terminal blocks required for connection (3 pieces)
3. Warranty Card
4. Installation instructions
5. Installation kit
Functions that don’t require internet connection:
1. Calls to apartment handsets by dialing the apartment number
2. Ability to open the door via handsets during the call
3. Ability to open the door using the “exit” button in the lobby
4. Door opening with RFID access keys
Functions that require internet connection:
1. Initial panel setup through the personal account
2. Call redirection to the mobile application
3. Door opening through the application
4. IP video surveillance with archive recording
5. Motion detection in the surrounding area
6. Door opening through facial recognition
7. Ability to add a photo for a facial recognition using the voice assistant
1. Supports connection to many popular intercom systems (Vizit, Eltis, CYFRAL)
2. Allows call redirection to the mobile phone application
3. Allows door opening through mobile phone application
4. Permits the door opening via face recognition
5. In case of loss of connection, continue to function as a regular intercom panel
6. Has the capability to use copy-protected RFID Mifare keys
7. Manages video surveillance of the surrounding area
Package contents:
1. Secret Top intercom (1 piece)
2. Terminal blocks required for connection (3 pieces)
3. Warranty Card
4. Installation instructions
5. Installation kit
Functions that don’t require internet connection:
1. Calls to apartment handsets by dialing the apartment number
2. Ability to open the door via handsets during the call
3. Ability to open the door using the “exit” button in the lobby
4. Door opening with RFID access keys
Functions that require internet connection:
1. Initial panel setup through the personal account
2. Call redirection to the mobile application
3. Door opening through the application
4. IP video surveillance with archive recording
5. Motion detection in the surrounding area
6. Door opening through facial recognition
7. Ability to add a photo for a facial recognition using the voice assistant
Important information:
- Firmware updates for the panel itself happen automatically through the internet but updates for the key reading devices are done manually
- To operate without a dedicated IP address, a network with properly configured DHCP, DNS and NTP is required
- All the keys that were uploaded through the personal account are stored on the panel itself, so they will function even without internet connectivity
- The panel doesn’t have an analog output making it incompatible with analog surveillance systems
- The panel doesn’t support SIP monitors
- Ability to automatically calibrate handsets
- SMD handsets aren’t supported
- The panel can work with gates and additional doors
- The panel has “White list” and “Black list” functions. In the first case, calls will be directed to the mobile application even if the physical handset isn’t installed. In the second case with Black list, calls on handset will be blocked for the specific apartment
- The panel allows you to set a custom greeting, which updates automatically on all your panels
- Firmware updates for the panel itself happen automatically through the internet but updates for the key reading devices are done manually
- To operate without a dedicated IP address, a network with properly configured DHCP, DNS and NTP is required
- All the keys that were uploaded through the personal account are stored on the panel itself, so they will function even without internet connectivity
- The panel doesn’t have an analog output making it incompatible with analog surveillance systems
- The panel doesn’t support SIP monitors
- Ability to automatically calibrate handsets
- SMD handsets aren’t supported
- The panel can work with gates and additional doors
- The panel has “White list” and “Black list” functions. In the first case, calls will be directed to the mobile application even if the physical handset isn’t installed. In the second case with Black list, calls on handset will be blocked for the specific apartment
- The panel allows you to set a custom greeting, which updates automatically on all your panels
Instructions
It is recommended to set up a testing unit in the office for configuring intercom Secret TOP. The will assist in training new personnel and conducting certification for specialists involved in installation, maintenance and sales of the smart intercom services.
