Making of a testing unit
When you turn on the SECRET TOP call block for the first time (with the Internet connected), it is recommended not to turn it off for 5 minutes to update the firmware, in order to avoid malfunctions
To connect the Secret TOP call block on the table you will need the following set of equipment and tools:
- Small Phillips screwdriver;
- Small flat screwdriver;
- Power supply 24V, 72W, 3A Rexant connected to a 220 V power supply;
- SECRET TOP call block;
- Internet network with a throughput of 5 Mbit/s.
We also recommend for installation:
- Exit button B-21 Eltis, Visit EXIT 300M or similar;
- Electromagnetic lock (up to 400 kg) M2-400 Olevs, Tantos TS-ML300 or similar (12 Volt power supply );
- Intercom switch KM100 Eltis, Visit BK-100M or similar (From supported manufacturer);
- ELTIS A5 handset, Visit UKP-7 or similar;
- Contactless key Mifare classic 1K.
Remove the Secret TOP call block from the box.
Next, unscrew the fastening screws the rear metal panel of the Call Unit and remove it. When mounting a panel using a casing, the rear panel is not required.
- Small Phillips screwdriver;
- Small flat screwdriver;
- Power supply 24V, 72W, 3A Rexant connected to a 220 V power supply;
- SECRET TOP call block;
- Internet network with a throughput of 5 Mbit/s.
We also recommend for installation:
- Exit button B-21 Eltis, Visit EXIT 300M or similar;
- Electromagnetic lock (up to 400 kg) M2-400 Olevs, Tantos TS-ML300 or similar (12 Volt power supply );
- Intercom switch KM100 Eltis, Visit BK-100M or similar (From supported manufacturer);
- ELTIS A5 handset, Visit UKP-7 or similar;
- Contactless key Mifare classic 1K.
Remove the Secret TOP call block from the box.
Next, unscrew the fastening screws the rear metal panel of the Call Unit and remove it. When mounting a panel using a casing, the rear panel is not required.
Next, you need to choose which intercom system you will connect with:
ELTIS
ELTIS up to 100 apartments (in the following text, the word apartments will be shortened as ap-ts)
ELTIS up to 200 ap-ts (Need switches KM100-7.2 or newer)
ELTIS up to 300 ap-ts (Need switches KM100-7.3 or newer)
ELTIS up to 499 ap-ts (KM100-7.5 switches are needed)
CYFRAL
Only one CYFRAL switch is supported
Important! Don't forget to connect power to the switch
"БК" - SM (Switching Module)
Important! Don't forget to connect power to the switch
"БК" - SM (Switching Module)
Beward KKM-100S2
Connection of only one Beward KKM-100 switch is supported
(The operating mode "Cyfral" is required.)
Important! Don't forget to connect power to the switch
"БК" - SM (Switching Module)
(The operating mode "Cyfral" is required.)
Important! Don't forget to connect power to the switch
"БК" - SM (Switching Module)
VISIT
(Secret Top versions 2.1 and 2.3)
(Secret Top versions 2.1 and 2.3)
Connection of only one Vizit switch is supported
"БК" - SM (Switching Module)
"БК" - SM (Switching Module)
VISIT
(Secret Top versions 2.5 and later)
(Secret Top versions 2.5 and later)
Supports connection of one or two switches directly to the panel, or four Vizit switches via BK400
When using more than one switch and if there are several input groups (additional doors), all additional panels must be configured as gates
"БК" - SM (Switching Module)
When using more than one switch and if there are several input groups (additional doors), all additional panels must be configured as gates
"БК" - SM (Switching Module)
FAKTORIAL
(Only supported in Secret Top 2.3 and later)
Connection of only one Factorial switch is supported
Important! Instead of an external Factorial power supply, you can use a +24V panel power supply
Important! Instead of an external Factorial power supply, you can use a +24V panel power supply
МЕТАКОМ
(Only supported in Secret Top 2.3 and later)
(Only supported in Secret Top 2.3 and later)
Connection of up to eight Metacom switches is supported
(When connected several Metacom switches are needed set their numbers with jumpers)
"БК" - SM (Switching Module)
Two doors, Vizit
(Only supported in Secret Top 2.3 and later)
(Only supported in Secret Top 2.3 and later)
Supports connection of up to three Secret Top panels in parallel, to implement a scheme with several entrances to the building
Attention
Works with only one switch
When using more than one switch, the second panel must be configured as a gate
"БК" - SM (Switching Module)
Attention
Works with only one switch
When using more than one switch, the second panel must be configured as a gate
"БК" - SM (Switching Module)
Two doors, Eltis
(Only supported in Secret Top 2.3 and later)
(Only supported in Secret Top 2.3 and later)
Supports connection of up to three Secret Top panels in parallel, to implement a scheme with several entrances to the building
"БК" - SM (Switching Module)
"БК" - SM (Switching Module)
Digital tubes
If digital handsets are used at the site, they can be connected via an interface device interface converter DP-K2D.
For it to work - select Eltis mode (For version Secret Top 2.3 and newer - select "Digital")
For it to work - select Eltis mode (For version Secret Top 2.3 and newer - select "Digital")
Connection of peripheral devices (switches, exit button on the entrance side) is carried out through terminal blocks located on the back side of the casing. The markings of the connection terminals are shown on the board.
1. Connect the terminals on the call block board (according to the diagrams above)
2. Connect the terminals on the switch (according to the diagrams above)
3. Connect the electromagnetic lock (if available) according to the diagram
2. Connect the terminals on the switch (according to the diagrams above)
3. Connect the electromagnetic lock (if available) according to the diagram
4. Connect the output button (if available) according to the diagram (select the diagram according to the number of wires, installation colors and polarity are important)
5. Connect to the Internet
6. Connect the output button (if available) according to the diagram (installation colors and polarity are important)
6. Connect the output button (if available) according to the diagram (installation colors and polarity are important)
7. Connect the output button (if available) according to the diagram (installation colors and polarity are important)
Examination
At the end of this section of the instructions, the following should work for you: - the screen with the inscription lights up
- the exit button works
- handset is ringing, if you are using an Eltis switch
At the end of this section of the instructions, the following should work for you: - the screen with the inscription lights up
- the exit button works
- handset is ringing, if you are using an Eltis switch
Note
1. Secret Top intercom panel supports the following switches:
● Eltis KM20-1 (1 piece)
● Eltis KM100-7.1 (1 piece)
● Eltis KM100-7.2 (up to 2 pieces connected in series)
● Eltis KM100-7.3 (up to 3 pieces connected in series)
● Eltis KM100-7.5 (up to 5 pieces connected in series)
● Cyfral KMG-100 (1 piece)
● Beward KKM-100 (1 piece)
● Visit BK-10 (up to 3 units connected in series)
● Visit BK-30M (up to 3 units connected in series)
● Visit BK-100M (1 piece)
● Factorial switch (1 piece)
2. Rules for setting switch settings: It is necessary to set the minimum and maximum apartment in the settings.
Operating modes (MODE):
1- If all handsets are connected to ports according to increasing port numbers, and it is not necessary to include apartments with a higher number in the initial ports of the switch, then this Operating mode in order (MODE 1).
2 - If the following conditions are met:
- Apartments are moving from one hundred to another;
- Apartments moving to the next hundred are connected to the initial ports of the switches. Then: In this case, the Cross numbering operating mode (MODE 2) is used ).
ATTENTION
Port D0E0 of Eltis and Cyfral is considered as port 100. Accordingly, in the operating mode in order (MODE 1), a maximum of 99 handsets can be connected to a switch with 100 ports.
For Visit brand switches, only the operating mode with one SEL (MODE 1) is possible. There are no other modes yet.
The offset is set depending on the connection of subscribers to the switch ports.
The switch port number can be found in the information topic /TELE/NUMBER.
3. Examples:
Given:
Apartments from 37 to 72, (switch for 100 ap-ts)
Option 1: You can connect ap-t 37 tubes to port D3E7 ... ap-t 72 to port D7E2 In this case, the offset is 0
Option 2: You can connect ap-t 37 tubes to port D0E1 ... ap-t 72 to port D3E6V In this case, the offset is 36
Given:
Apartments from 289 to 324 (switch for 100 ap-ts)
Option 1: You can connect the ap-t 289 tubes to port D0E1 ... ap-t 324 to port D3E5, the switch jumper is set to 0. In this case, the operating mode is in order (MODE 1), and the offset is 289
Option 2: You can connect the ap-t 289 tubes to port D0E1 ... ap-t 324 to the D3E6 port, the switch jumper is set to 200 In this case, the operating mode is in order (MODE 1), and the offset is 89
Option 3: You can connect the ap-t 289 tubes to the D8E9 port. .. ap-t 324 to port D2E4, the switch jumper is set to 200. In this case, the operating mode is cross numbering (MODE 2), and the offset is 0.
Option 4: You can connect the tubes ap-t 289 to port D8E9 ... ap-t 324 to port D2E4, the switch jumper is set to 0. In this case cross numbering operating mode (MODE 2), and offset 200
1. Secret Top intercom panel supports the following switches:
● Eltis KM20-1 (1 piece)
● Eltis KM100-7.1 (1 piece)
● Eltis KM100-7.2 (up to 2 pieces connected in series)
● Eltis KM100-7.3 (up to 3 pieces connected in series)
● Eltis KM100-7.5 (up to 5 pieces connected in series)
● Cyfral KMG-100 (1 piece)
● Beward KKM-100 (1 piece)
● Visit BK-10 (up to 3 units connected in series)
● Visit BK-30M (up to 3 units connected in series)
● Visit BK-100M (1 piece)
● Factorial switch (1 piece)
2. Rules for setting switch settings: It is necessary to set the minimum and maximum apartment in the settings.
Operating modes (MODE):
1- If all handsets are connected to ports according to increasing port numbers, and it is not necessary to include apartments with a higher number in the initial ports of the switch, then this Operating mode in order (MODE 1).
2 - If the following conditions are met:
- Apartments are moving from one hundred to another;
- Apartments moving to the next hundred are connected to the initial ports of the switches. Then: In this case, the Cross numbering operating mode (MODE 2) is used ).
ATTENTION
Port D0E0 of Eltis and Cyfral is considered as port 100. Accordingly, in the operating mode in order (MODE 1), a maximum of 99 handsets can be connected to a switch with 100 ports.
For Visit brand switches, only the operating mode with one SEL (MODE 1) is possible. There are no other modes yet.
The offset is set depending on the connection of subscribers to the switch ports.
The switch port number can be found in the information topic /TELE/NUMBER.
3. Examples:
Given:
Apartments from 37 to 72, (switch for 100 ap-ts)
Option 1: You can connect ap-t 37 tubes to port D3E7 ... ap-t 72 to port D7E2 In this case, the offset is 0
Option 2: You can connect ap-t 37 tubes to port D0E1 ... ap-t 72 to port D3E6V In this case, the offset is 36
Given:
Apartments from 289 to 324 (switch for 100 ap-ts)
Option 1: You can connect the ap-t 289 tubes to port D0E1 ... ap-t 324 to port D3E5, the switch jumper is set to 0. In this case, the operating mode is in order (MODE 1), and the offset is 289
Option 2: You can connect the ap-t 289 tubes to port D0E1 ... ap-t 324 to the D3E6 port, the switch jumper is set to 200 In this case, the operating mode is in order (MODE 1), and the offset is 89
Option 3: You can connect the ap-t 289 tubes to the D8E9 port. .. ap-t 324 to port D2E4, the switch jumper is set to 200. In this case, the operating mode is cross numbering (MODE 2), and the offset is 0.
Option 4: You can connect the tubes ap-t 289 to port D8E9 ... ap-t 324 to port D2E4, the switch jumper is set to 0. In this case cross numbering operating mode (MODE 2), and offset 200
Unlocking the door
The door can be unlocked in the following ways
1. Through the "exit button" connected to the panel
2. Via the open button on the intercom handset during a conversation
3. Via personal RFID key
4. Via the open button in the application
5. Through the "face recognition" button, if this function is activated
When you press the exit button, the panel emits a sound notification that the door is unlocked, the same information is presented on the screen. At the time of the sound notification, conversation through the panel is impossible. When you press the open button during a call in the application, the door is unlocked and the call stops. When the door is unlocked along the contour of the face, the door is unlocked and an audible greeting from the operator is heard.
The door can be unlocked in the following ways
1. Through the "exit button" connected to the panel
2. Via the open button on the intercom handset during a conversation
3. Via personal RFID key
4. Via the open button in the application
5. Through the "face recognition" button, if this function is activated
When you press the exit button, the panel emits a sound notification that the door is unlocked, the same information is presented on the screen. At the time of the sound notification, conversation through the panel is impossible. When you press the open button during a call in the application, the door is unlocked and the call stops. When the door is unlocked along the contour of the face, the door is unlocked and an audible greeting from the operator is heard.
