Connection on site
When you turn on the SECRET MINI call block for the first time (with the Internet connected), it is recommended not to turn it off for 5 minutes to update the firmware, in order to avoid malfunctions.
To disconnect the Secret MINI call block on the table, you will need the following set of equipment and tools:
- a small Phillips screwdriver;
- a small flat screwdriver;
- SECRET MINI panel;
- Internet network with a bandwidth of 5 MB/s.
- Intercom system from the list of those supported by the Secret MINI panel. We also recommend for installation:
- EM-Marine contactless key.
- PoE power supply connected to a 220 V power supply.
The Secret Mini intercom panel supports the following intercom models:
- a small Phillips screwdriver;
- a small flat screwdriver;
- SECRET MINI panel;
- Internet network with a bandwidth of 5 MB/s.
- Intercom system from the list of those supported by the Secret MINI panel. We also recommend for installation:
- EM-Marine contactless key.
- PoE power supply connected to a 220 V power supply.
The Secret Mini intercom panel supports the following intercom models:
Remove the Secret MINI call unit from the box. Further, you need to choose which intercom system you will connect with:
All of the connections schemes listed below also appear in this document
All of the connections schemes listed below also appear in this document
Recommended installation diagram
Recommendations for installation:
1. The Secret MINI calling panel is installed at the entrance, to the left of the door, on the wall or the second door leaf.
2. If there is an apartment intercom, the Secret MINI calling panel is installed above the intercom calling block.
3. The recommended distance from the edge of the door (wall) to the calling panel is minimum 10 cm.
4. For the best view, the recommended installation height is H=1.5m, at a distance from the floor to the video camera
5. If necessary, use an installation kit with a visor; the mounting holes are the same size and distance as the Secret MINI holes.
1. The Secret MINI calling panel is installed at the entrance, to the left of the door, on the wall or the second door leaf.
2. If there is an apartment intercom, the Secret MINI calling panel is installed above the intercom calling block.
3. The recommended distance from the edge of the door (wall) to the calling panel is minimum 10 cm.
4. For the best view, the recommended installation height is H=1.5m, at a distance from the floor to the video camera
5. If necessary, use an installation kit with a visor; the mounting holes are the same size and distance as the Secret MINI holes.
Approximate set of equipment for 1 door
SECRET MINI panel installation
Stencil
