Setting up the operating mode through your Personal Account

When you turn on the SECRET MINI call block for the first time (with the Internet connected), it is recommended not to turn it off for 5 minutes to update the firmware, in order to avoid malfunctions

You need to log into the provider’s personal account using the credentials provided by the manager at my.domovoy.city. In your personal account, enter the address where the panel will be installed using the instructions for establishing an address, if you already have the required address set up, you can skip this item.
Next, to create an intercom, click the “Add intercom” button, select “SECRET MINI call block” in the window that opens.

Fill in the fields Address, Entrance, Range of apartments.

Enter the mac address of the panel (indicated on the box and on the back of the panel) and the corresponding intercom type from the drop-down list and the corresponding settings. (Example with type Vizit)

Rules for setting switch settings:


It is necessary to set the minimum and maximum apartment in the settings.

Operating modes (MODE):
1. If all handsets are connected to ports according to increasing port numbers, and there is no need to include apartments with a higher number in the initial ports of the switch, then this is Operation in order mode (MODE 1)
2. If the following conditions are met:
- Apartments move from one hundred to another;
- Apartments moving to the next hundred are connected to the initial ports of the switches. In this case, the Cross Numbering Operation Mode (MODE 2) is used.
ATTENTION
Port D0E0 of the Eltis and Cyfral switches is considered as port 100. Accordingly, in the operating mode in order (MODE 1), a maximum of 99 handsets can be connected to a switch with 100 ports. For Visit brand switches, only the Mode of operation with one SEL (MODE 1) is possible; there are no other modes yet. The offset is set depending on the connection of subscribers to the switch ports. Number of the switch port can be viewed in the information topic /TELE/NUMBER1.

Examples
Given: Apartments from 37 to 72, Eltis KM100-7.1 (1 piece)
Option 1: You can connect ap-t 37 tubes to port D3E7 ... ap-t 72 to port D7E2 In this case, the offset is 0
Option 2: You can connect ap-t 37 tubes to port D0E1 ... ap-t 72 in port D3E6. In this case, the offset is 36

Given:
Apartments from 289 to 324 Eltis KM100-7.3 (1 piece)
Option 1: You can connect the ap-t 289 tubes to the port D0E1 ... ap-t 324 to the port D3E5, the switch jumper is set to 0 In this case, the operating mode is in order (MODE 1), and the offset is 289
Option 2: You can connect the ap-t 289 tubes to port D0E1 ... ap-t 324 to the D3E6 port, the switch jumper is set to 200. In this case, the operating mode is in order (MODE 1), and the offset is 89
Option 3: You can connect the ap-t 289 tubes to the port D8E9 ... ap-t 324 to port D2E4, the switch jumper is set to 200. In this case, the operating mode is cross numbering (MODE 2), and the offset is 0
Option 4: You can connect the tubes ap-t 289 to port D8E9 ... ap-t 324 to port D2E4, the switch jumper is set to 0V
In this case, the operating mode is cross numbering (MODE 2), and the offset is 20


Next, indicate the name of the camera and select the tariff, time zone, access level, and management of rights to the camera.


The Secret MINI panel has now been added

Upon completion, in the SECRET MINI Call Block section, a panel will appear to which the camera will be linked.

Camera in the application and cloud.ucams.ru. It will start working within 10-15 minutes.


Examination

At the end of this section of the instructions, the following should work for you:

the key reader lights up in red;
the ring around the button lights up in white.

If the ring doesn’t light up, it means the panel has not yet been configured in your Personal Account, or has not yet received settings from the server

Далее можете переходить к созданию учетных записей для жильцов дома инструкция для заведения пользователя.
